Parameterizing and Configuring
Configuring devices at Modbus TCP
80
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
TBEN-S2-8DIP – parameter registers
Parameter description [}39]
Register no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Channel 0
0xB000 IST DI0 DIFT
DI0
DMOD_CNT DI0
Channel 1
0xB001 IST DI1 DIFT
DI1
DMOD DI1
…
Channel 7
0xB007 IST DI7 DIFT
DI7
DMOD DI7
VAUX
0xB009 - - - - - - VAUX1 Pin1
C1 (Ch2/3)
- - - - - - VAUX1 Pin1
C0 (Ch0/1)
0xB00A - - - - - - VAUX1 Pin1
C3 (Ch6/7)
- - - - - - VAUX1 Pin1
C2 (Ch4/5)
