Tusa ELEMENT - ALPHA; NUMERIC DISPLAYS; Depth Displays

11
ALPHA / NUMERIC DISPLAYS
Each numeric and graphic display represents a
unique piece of information. It is imperative that you
understand the formats, ranges, and values of the
information represented to avoid any possible mis-
understanding that could result in error.
Depth Displays
During a dive, the Current Depth display (Fig. 3Aa), indicates
depths from 0 to 330 FT (99.9 M) in 1 FT (0.1 M) increments.
The Maximum Depth reached during that dive is displayed
on an Alternate screen by pressing the button (Fig. 3Ba).
During a No Deco Dive Deep and Safety Stops and while in
Decompression, the required Stop Depth is displayed on the
Main (Fig. 4a).
Fig. 4 - STOP DEPTH
a
a
Fig. 3A - CURRENT DEPTH
a
Fig. 3B - MAX DEPTH
