63
BAR GRAPHS
Nitrogen Bar Graph segments Oxygen (O2) Bar Graph: segments
• No Deco Normal zone 3 • Normal zone 3
• No Deco Caution zone 1 • Caution zone 1
• Decompression Warning zone 1 • Danger zone 1
Variable Ascent Rate Indicator: 60 FT (18 M) & Shallower Deeper than 60 FT (18 M)
segments FPM MPM segments FPM MPM
0 0 - 10 0 - 3 0 0 - 20 0 - 6
• Normal Zone 1 11 - 25 3.5 - 7.5 1 21 - 50 6.5 - 15
• Caution Zone 2 26 - 30 8 - 9 2 51 - 60 15.5 - 18
• Too Fast Zone (flashing) 3 (all) > 30 > 9 3 (all) > 60 > 18
OPERATIONAL PERFORMANCE
Function: Accuracy:
• Depth ±1% of full scale
• Timers 1 second per day
Dive Counter:
• Displays Dives #1 to 12, 0 if no dive made yet.
• Resets to Dive #1, upon reactivation after having shut off.
SPECIFICATIONS (CONTINUED)
