Page 10 of 56
Property
Value
Weight
66 kg (145.5 lb)
Weight per support area (max. load)
1.71 N/m2
(0.036 lb/ft2)
Shipping weight
71 kg (156 lb)
Width
63 cm (24.8”)
Height
71 cm (28.0”)
Length
80 cm (35.8”)
Shipping dimensions
Volume
0.36 m3 (14.5 ft3)
Max. water
volume
6.6 lit. (1.74 US gal)
Mineral-free water reservoir
Min. water
volume
2.6 lit. (0.68 US gal)
Used (waste) water reservoir
Max. water
volume
5.2 lit. (1.37 US gal)
3.5. Utilities
Utility Value
Mineral free water See table in para 3.10.
Power supply 1 phase, 208/240Vac, 50/60Hz
Recommended circuit breaker 15A
Attention:
The electrical net must be protected with a current leakage safety relay.
The electrical network must comply with local rules or regulations.
3.6. Environment Emission Information
1. The peak sound level generated by the autoclave is 65dBa with
background noise of 48 dBa.
2. The total heat per hour transmitted by the autoclave is <200Wh.
3.7. Electrical Data
Property Value
Total Power 2300W
Voltage
1 ph / 230 Vac
Amperage 10A
Protection against electrical shock Class I (IEC 60601-1)
Mains supply fluctuation +/- 10%
Note:
In order to avoid any injury by electrical hazard, it is
recommended that a ground fault protection device be installed in
the electrical panel feeding the autoclave (local codes may make
this mandatory).
