Description No. Description
1 Water reservoir funnel 10 Operating key board
2 Autoclave cover 11 Printer cover
3 Water level side gauge 12 Printer (option)
4 Mineral-free water reservoir cover 13 Legs
5
Chamber and steam generator safety
valves
14 Waste water reservoir drain valve
6 Waste water reservoir cover 15
Mineral-free water reservoir drain
valve
7
Display 16 Door cover
8 Ventilation grill 17 Door switch
9 Main switch circuit breaker 18 Door closing device
5 4 6
8
9
101115 13 12
1 2 3
718
17
16
13 14
