PRINTER OUTPUT DESCRIPTION
Operator: To be filled in manually by operator
Time: 17:09:08 Time sterilization cycle ended
Date: 13/02/2006 Date sterilization cycle ended.
CYCLE ENDED!
D 00:48:46 077.4 036.2 The time, temperature and pressure during drying.
*
* Prints drying data every 3 minutes.
*
D 00:30:46 104.8 109.2 The time, temperature and pressure during drying.
-----------------------
E 00:30:07 122.0 211.6 The time, temperature and pressure during exhaust.
-----------------------
S 00:30:07 134.1 311.3 The time, temperature and pressure during sterilization.
*
* Prints sterilization data every 1 minute.
*
S 00:10:06 121.1 210.0 The time, temperature and pressure during sterilization.
----------------------
H 00:08:57 077.4 058.3 The time, temperature and pressure during heating.
----------------------
V 00:08:57 077.4 058.3 The time, temperature and pressure during air removal.
*
*
*
Prints sterilization data every 3 minute or on upper and
lower peak (the shorter time)
V 00:00:00 078.1 095.0 The time, temperature and pressure during air removal.
Time °C kPa Time, temperature and pressure columns
Dry Time: 020.0min Drying time for selected program.
Ster Time: 020.0min Sterilization time for selected program.
Ster Temp: 121.0°C Sterilization temperature in chamber for selected program
Cycle: WDry Cycle name (with dry).
Load number: 00933 Cycle counter
Param. Ver: 0030 Version of parameters setting
Ver: Nova 4 1.20 Software version.
Ser.Num: 02304101 Autoclave's serial number.
Time: 16:18:22 Time sterilization cycle started.
Date: 13/02/2006 Date sterilization cycle started.
POWER ON The device is turned on
Time: 16:16:16 Start time
Date: 13/02/2006 Start date
POWER OFF
--------------------
The device is turned off
Legend
V Vacuum stage
H Heating stage
S Sterilization stage
E Exhaust stage
D Drying stage
T Test
