Page 52 of 56
11.5.2 PED-approved type safety valve
1. Operate the sterilization cycle according to the manual.
2. Allow a pressure of approx. 200 kPa (29-psi) to build up
in the generator and the chamber.
3. Remove the water reservoir cover.
4. Turn the pressure relief nut clockwise for 2 seconds.
Verify steam escapes from the valve.
Attention:
Use protective gloves in order not to burn your hands with
the hot steam.
5. Press the STOP key to interrupt the operation, and
exhaust steam from the chamber.
6. Wait until the pressure decreases to zero, only then can
the door be opened.
No. Description
1 water reservoir cover
5 Safety valve
6 pressure relief nut
5 6
