Page 10 of 83 Pages
3.4 Environment Emission Information
A. Peak sound level generated by the sterilizer is « 70 / dBA with a back
sound level of 60 dBA.
B. Total heat transmitted by the sterilizer is < 100 W/h
3.5 Electrical Data
PROPERTIES
208V
version
230V
version
380V
version
Ampere (A) at 3Ph 24A 24A 14A
Voltage (V) 208V/3ph 230V/3ph 380V/3ph
Hertz (Hz) 50/60 Hz 50/60 Hz 50/60 Hz
Heaters power (W) 9000 9000 9000
Protection against electrical shock Class I Class I Class I
Degree of protection by enclosure IP31 IP31 IP31
3.6 Specifications
PROPERTIES
MODEL
5050 5075
Chamber diameter in mm 500 500
Chamber depth in mm 520 750
Effective Chamber volume
102 lit.
27 US gal
160 lit.
42.3 US gal
Overall
dimensions
Height (mm) 950 1100
Width (mm) 866 866
Length (mm) 715 715
Maximum
dimensions
(door open)
Width (mm) 960 960
Height (mm) 1538 1688
Net weight (kg) 171 190
Shipping volume (m
3
) 1.35 1.35
Shipping weight (kg) 204 223
Max. Allowable Working
pressure (MAWP)
2.8 bar (40 psi)
3.7 Construction
Chamber and door material
Stainless steel
Outer Cabinet Stainless Steel
Chamber insulation Fiberglass with reinforced material
