3.8 Loading Capacities
3.8.1 solid load
Maximum solid load: 7 kg (15.5 lb)
3.8.2 Erlenmeyer Flasks
Size
250 ml 500 ml 1000 ml
Qty
5050
2 x 21 2 x 14 2 x 8
5075
3 x 21 3 x 14 3 x 8
3.8.3 Medium Flasks (Schott)
Size
250 ml. 500 ml 1000 ml
Qty
5050
2 x 32 2 x 21 2 x 15
5075
3 x 32 3 x 21 3 x 15
3.9 Utilities
3.9.1 Electrical utility
Power Switch box
Recommended
Circuit Breaker
208-220V (3 Ph + Earthing) No 32A
380-400V(3 Ph + Neutral +
Earthing)
No 16A
230V 1ph yes 50A
Frequency 50/60Hz
3.9.2 Other utilities
Compressed Air (ELVC-D
only)
1/2" 3-4 Bar (44-58 psi)
Tap water 1/2", 2-3 Bar (29-44 psi)
Mineral free water 1/2", 2-3 Bar (29-44 psi)
Drain
2" Minimum Withstanding temp.
of 80°C (176°F)
Attention:
A switch or circuit-breaker must be included in the building
installation. This switch or circuit-breaker shall be in close proximity
to the equipment, within easy reach of the operator; and marked as the
disconnecting device for the equipment.
The electrical net must be protected with a current leakage safety relay.
The electrical network must comply with local rules or regulations.
Verify that there is an easy access to the main power switch, to the
water cut-off valve and to the current leakage safety relay.
Make sure while placing the autoclave, to leave space around the
machine, to give the technician access to service the machine.
