Tuttnauer ELV-D - Front View

Page 13 of 83 Pages
FRONT VIEW
No. Description
1
Front leg
2
Rear leg
3
Left service door
4
Left service door grip
5
Service door lock screws
6
Door cover
7
Pressure gauge
8
Display
9
Keyboard
10
Printer cover
11
Paper slot and paper cutter
12
Printer
13
Main switch
14
RJ45 connector
15
USB socket
9 105 6 7 8
11
14
15
4
3
2
1
12
13
