4.1.2 Keypad
The keypad consists of three keys as described below:
UP key
This key has the following functions:
In the menu directories:
o This key enables the operator to browse
through the cycles.
In the directories available:
o When the cursor is blinking on a number,
the
UP ▲ key increases its value.
o When the cursor is blinking on a menu
selection, the
UP ▲ key allows browsing
backward through the menu.
o When adjusting a parameter and the cursor
is blinking on “SET” or “EXIT” the
UP ▲
key activates that procedure.”
DOWN key
This key has the following functions:
In the menu directories:
o This key enables the operator to browse
through the cycles.
In the directories available:
o When the cursor is blinking on a number,
the
DOWN ▼ key decreases its value.
o
When the cursor is blinking on menu
selection, the DOWN
▼
key allows
browsing forward through the menu.
o When adjusting a parameter and the cursor
is blinking on “SET” or “EXIT” the
DOWN
▼
key activates that procedure.
START/STOP key
This key has the following functions:
In the main screen:
o Starts the process when the required
program was chosen.
o Stops the current process.
o Cancels the ERROR message displayed on
the screen and opens the electric door lock.
In the menu directories:
o When the cursor is blinking on a number,
the
START/STOP key enables moving
to the next position.
o When the cursor is blinking on a menu
selection, the
START/STOP key
activates that selection.
