Step 3: Mounting the caps Assembling the X/Y axes 33
8 x
6 x
16 x
16 x
image 31: parts needed for this step
The wooden caps have to be attached in four corners of the Ultimaker
Original+. To help you performing the actions, the following overview is
provided, see image 32.
image 32: overview dierent corners
B
A C
D
B
C
D
A
