103
Specifications
1240.0–1300.0
25 cm Amateur Band
Above bands in 12.5 kHz steps
108.0–136.9750
Aircraft Band
Above band in 25 kHz steps
Operating Temperature: –20°C to +60°C
Scan Rate: 100 channels per second
(conventional mode)
Search Rate: 300 steps per second
(5 kHz step only)
Scan Delay: 0-5 seconds
Audio Output: 2W nominal into
8 ohm internal speaker
Power Requirements: 12 VDC 500mAh
(AD140U AC adapter)
Antenna: 50 ohms (Impedance)
External Jacks: Antenna Jack BNC Type
Ext. Speaker Jack 3.5mm
Line Out Jack 3.5mm
DC Power Jack 5.5mm
Remote Jack D-sub9 Pins
Size: 10
1
/2 in. (W) x 7
3
/8 in. (D) x 3
1
/2 in. (H)
Weight: 3.8 lbs
Features, specifications, and availability of optional
accessories are all subject to change without notice.
