Uponor c56

Set automatic daylight saving
For European zone CET, an automatic time adjustment is made
complying with European directive 2000/84/EC.
For countries in the southern hemisphere, set the end date
earlier than the start date.
To set automatic daylight saving:
1 On the Uponor screen, select Main Menu > Settings >
System Parameters > Clock Settings > Auto Daylight
Saving.
2 Select the desired setting and press
OK.
3 Fixed date allows manual setting of
the dates.
Enter Start date and End date of
summer time and press OK.
9.16 Use ECO mode
Use ECO to save energy. In heating mode, ECO mode reduces
room temperatures at the set times. In cooling mode, it
increases the temperature. Different ECO profi les may be
applied to a thermostat for each day of the week.
The ECO profi le provides fi ve different time/temperature
profi les. The names indicate their specifi c application. All
profi les can be modifi ed. In the event of a power failure, all
customised settings are saved.
Cooling ECO profi les are displayed only when cooling is
activated and set in the system parameters menu.
ECO mode setting Description
ECO Off
ECO All
ECO mode active:
From 9.30 a.m. to 2.30 p.m.
ECO Night & Day
For example, ECO mode active:
From 10.30 p.m. to 5.00 a.m.
From 9.30 a.m. to 2.30 p.m.
ECO Custom
For example, ECO mode active:
From 00.30 a.m. to 5.30 a.m.
From 12.00 a.m. to 5.30 p.m.
ECO Night
For example, ECO mode active:
From 10.30 p.m. to 5.00 a.m.
The Uponor Remote access module R-56 allows switching
between Comfort mode and ECO mode, by using a mobile
telephone.
Edit ECO profi les
After making modifi cations, profi les cannot be reset to their
initial values, except by modifying them again.
Modify the profi les fi rst, then defi ne the thermostats that each
profi le controls. To edit ECO profi les:
1 On the Uponor screen, select Main Menu > Settings >
Edit ECO Profi les.
2 Select the ECO profi le to modify and
press OK.
Modify ECO profi le, then confi rm by
pressing OK.
3 To modify the profi le, select the time using the
and
keys to move in increments of 30 minutes. The set time is
indicated above the time profi le.
Apply Comfort mode by pressing the
key.
Apply ECO mode by pressing the
key.
4 To set a complete period with the same mode:
• Move the cursor to the start time of the period.
• Set the start time: by briefl y pressing the
or key.
• Move the cursor to the end time of the period.
• Press and hold the
or key.
The profi le applies from start time to end time.
5 Modify the correction value of the
temperature set point for the ECO
mode and press OK.
40
UPONOR CONTROL SYSTEM – INSTALLATION AND OPERATION MANUAL
UK English
