Uponor c56

Technical data
Usable in all Europe 0682
Declaration of conformity:
We hereby declare under our own responsibility that products dealt with
by these instructions satisfy all essential demands linked to the R&TTE
1999/5/CE Directive dated March 1999.
General
IP IP30 (IP: degree of inaccessibility to active parts of the product and
degree of water)
Max. ambient RH (relative humidity) 95% max. at 20 °C
Thermostat
CE marking
Low voltage tests EN 60730-1* and EN 60730-2-9***
EMC (electromagnetic compatibility
requirements) tests
EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and
radio spectrum matters) tests
EN 300 220-3
Approval and certifi cation
KNX Konnex approval and certifi cation
Power Two 1.5 V AAA alkaline batteries
Voltage 2.2 V to 3.6 V
Operating temperature 0 °C to +45 °C
Storage temperature -10 °C to +65 °C
Radio frequency 868.3 MHz
Transmitter duty cycle 1%
Interface
CE marking
Low voltage tests EN 60730-1 and EN 60730-2-1
EMC tests EN 60730-1
Power 11 V DC ±10% from controller
Operating temperature 0 °C to +55 °C
Storage temperature -20 °C to +70 °C
Max. consumption 1 W
Antenna
Power supply 11 V DC ±10% from controller
Consumption less than 1 W
Radio Frequency 868.3 MHz
Transmitter duty cycle 1%
Receiver class 2
Controller
CE marking
Low voltage tests EN 60730-1* and EN 60730-2-1**
EMC tests EN 60730-1 and EN 301-489-3
ERM tests EN 300 220-3
Power 230 V AC +10/-15%, 50 Hz
Operating temperature 0 °C to +55 °C
Storage temperature -20 °C to +70 °C
Max. consumption 70 W
Pump relay output 230 V AC +10/-15%, 250 V AC 2 μA max.
Heating/cooling input Only dry contact
Valve outputs 24 V DC ±10%, 436 mA max. for outputs 1 and 2
24 V DC ±10%, 218 mA max. for outputs 3 to 12
Power connection 1 m cable with europlug
Pump connection wires 1.5 mm² max
Heating/cooling connection wires 1.5 mm² max
*) EN 60730-1 Automatic electrical controls for household and similar use
-- Part 1: General requirements
**) EN 60730-2-1 Automatic electrical controls for household and similar use
-- Part 2-1: Particular requirements for electrical controls for electrical
household appliances
***) EN 60730-2-9 Automatic electrical controls for household and similar use
-- Part 2-9: Particular requirements for temperature sensing controls
