Upright TL33 - CHASSIS ASSEMBLY

7-2
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
CHASSIS ASSEMBLY
ITEM PART-NUMBER DESCRIPTION QTY.
1 57060-200 CHASSIS WELDMENT 1
2 57061-200 OUTRIGGER WELDMENT 4
3
*
*
57062-000
57062-001
57062-002
OUTRIGGER JACK ASSEMBLY
JACK HANDLE (AND NUT AND BOLT)
JACK SCREW (AND PIVOT PLATE)
4
4
4
4
57069-300 BRAKED AXLE ASSEMBLY 1
5 57099-300 MUDGUARD ASSEMBLY 2
6 57072-000 TYRE 6.7 - 13 6 PLY 2
7 57070-000 WHEEL RIM 2
8
8
57071-000
57474-000
WHEEL NUT - 1/2” U.N.F. SERIAL NUMBERS 1001 TO 1069
WHEEL NUT - M12 SERIAL NUMBERS 1070 TO CURRENT
8
8
9 57077-000 BRAKE CABLE ASSEMBLY 2
10 57078-300 BRAKE ROD 1
11 57182-400 OUTRIGGER LIMIT SWITCH 4
12 57030-400 OUTRIGGER PIVOT PIN 4
13 57379-000 GASKET FOR FILLER / BREATHER 1
14 57109-300 FILLER / BREATHER ASSEMBLY 1
15
15
57081-300
58240-300
COUPLING - SERIAL NUMBERS 1001 TO 1410
COUPLING - SERIAL NUMBERS 1411 TO CURRENT
1
1
16
*
16
*
57080-300
58242-000
JOCKEY WHEEL ASSEMBLY SERIAL NUMBERS 1001 TO 1410
CLAMP SLEEVE ASSEMBLY FOR 57461-000
JOCKEY WHEEL ASSEMBLY SERIAL NUMBERS 1411 TO CURRENT
CLAMP SLEEVE ASSEMBLY FOR 58263-000
1
1
17
*
*
*
15797-000
15797-010
15797-011
10145-001
MOTOR PUMP SET ASSEMBLY
PUMP
ELECTRIC MOTOR
BRUSH SET
1
18 15796-001 BATTERY 6V 220 Ah, DRY 4
19
19
19
63948-011
63944-011
63983-002
BATTERY CHARGER - E.U. 220/110VAC 50/60HZ
BATTERY CHARGER - U.S.A. 110VAC 60HZ
BATTERY CHARGER - JAPAN 100VAC 60HZ
1
20
20
57300-400
57475-300
PUMP MOTOR CONTROLLER - NO B.D.I.
SERIAL NUMBERS 1001 TO 1032
PUMP MOTOR CONTROLLER - WITH B.D.I
SERIAL NUMBERS 1033 TO CURRENT
1
1
21 57082-300 BATTERY CLAMP ASSEMBLY 4
22 57064-400 CAP 4
23 57063-400 LOCKING HANDLE 4
24 57065-400 SPRING 4
25 57066-400 GUIDE BLOCK 4
26 57067-400 LOCKING PIN 4
27
*
57025-300
57510-000
COVER
RUBBER LATCH
2
4
28 57291-300 BOOM REST 1
29 57375-000
57107-000
FILTER ASSEMBLY (NO FITTINGS)
FILTER ASSEMBLY (WITH FITTINGS)
1
1
OPTIONS
# 1
*
*
*
*
*
*
57130-000
57070-300
57072-300
57016-300
56060-100
56064-000
56069-010
SPARE WHEEL OPTION
WHEEL RIM
TYRE
MOUNTING BRACKET
BOLT
NUT
WASHER
1
1
1
1
2
2
2
