Upright TL33 User Manual

7-10
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
HUB ASSEMBLY
57058-000
ITEM PART-NUMBER DESCRIPTION QTY.
1
57056-000
57057-000
LEFT HAND BRAKE ASSEMBLY
RIGHT HAND BRAKE ASSEMBLY
1
2 58871-000 GREASE SEAL 1
3 57083-000 INNER BEARING 1
4 57084-000 OUTER BEARING 1
5 - SPLIT PIN 1
6 - RETAINING NUT & WASHER 4
7 57086-000
57471-000
WHEEL STUD - 1/2” UNF SERIAL NUMBERS 1001 TO 1069
WHEEL STUD - M12 SERIAL NUMBERS 1070 TO CURRENT
8
8
8 57071-000
57474-000
WHEEL NUT - 1/2” UNF SERIAL NUMBERS 1001 TO 1069
WHEEL NUT - M12 SERIAL NUMBERS 1070 TO CURRENT
8
8
9 57087-000 DRUM 1
10 - WASHER 1
11 - AXLE NUT 1
12 58898-000 HUB CAP 1
