Upright TL33 - AXLE AND BRAKE HUB ASSEMBLY

7-8
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
AXLE AND BRAKE HUB ASSEMBLY
57069-300
ITEM PART-NUMBER DESCRIPTION QTY.
1 57059-000 AXLE BEAM ASSEMBLY 1
2 57058-000 WHEEL HUB ASSEMBLY 2
3 57056-000 BRAKE ASSEMBLY (LEFT HAND) 1
4 57057-000 BRAKE ASSEMBLY (RIGHT HAND) 1
5
5
57071-000
57474-000
WHEEL NUT - 1/2” UNF SERIAL NUMBERS 1001 TO 1069
WHEEL NUT - M12 SERIAL NUMBERS 1070 TO CURRENT
8
8
6
6
57086-000
57471-000
WHEEL STUD - 1/2” UNF SERIAL NUMBERS 1001 TO 1069
WHEEL STUD - M12 SERIAL NUMBERS 1070 TO CURRENT
8
8
