1-2
TL33 Work Platform
Introduction & Specifications
Section
1.2
Purpose and limitations
The purpose of the TL33 work platform is to provide a quickly deployable, trailer mounted, variable height work platform.
It is capable of lifting two people with work tools up to an upper limit of 215kg in total. The unit will provide the ability to
reach over obstacles and may be used on uneven firm ground provided the chassis is correctly levelled using the screw
jack adjusters prior to elevating.
The platform must only be used on firm level ground capable of supporting
the maximum load generated under the outriggers. All outriggers must be
correctly deployed and the chassis levelled before use. Do not use on soft
or severely sloping ground.
1.2 Specifications*
Table 1-1: Specifications
ITEM METRIC IMPERIAL
Duty Cycle
30% of 8hr cycle
Platform Size
0.7m x 1.3m (inside guardrails) 2.3 ft x 4.3ft
Max. Platform Capacity
215Kg 473 lbs
Max. No. of occupants
2 People
Max. Working Height
12.3m 40.3 ft
Max. Platform Floor Height
10.3m 33.8 ft
Max. Working Outreach
5 m 16.4 ft
Travelling Dimensions:
Length
Width
Height
5.5 m
1.6 m
1.99m
18 ft
4.9 ft
6.5 ft
Stabiliser spread
3 m X 3m 10 ft x 10 ft
Rotation
360
o
non-continuous
Gross weight
1209 Kg 2660 lbs
Max. Towable speed
83 Km/Hr. ** 50 mph **
Energy source
24V DC 4HP, 4 x 6V
220 Ah batteries
System Voltage
24V
Battery Charger
24V 25A 220/110VAC 50/60 Hz
Hydraulic Tank Capacity
8 Litres 2.1 Gallons
Max. Hydraulic System Pressure
140 Bar 2030 P.S.I
Hydraulic Fluid
ISO # 46
Lift System
2 x Double acting lift cylinders with lock
valves and manual emergency lower facility
Control System
One-hand proportional joystick operating
energy-efficient motor control system
Tyres
6PLY R13
Braking
Automatic reverse and overrun brakes plus
handbrake.
*Specifications subject to change without notice.
** Max. speed is subject to traffic regulations in the country in question.
CAUTION
