Upright TL33 - Slew Gearbox Assembly

7-14
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
SLEW GEARBOX ASSEMBLY
57041-300
ITEM PART-NUMBER DESCRIPTION QTY.
1 - GEARBOX HOUSING 1
2 - BEARING HOUSING 1
3 - TOP CAP 1
4 - WORM CAP 1
5 - GEAR WHEEL 1
6 - WORM 1
7 - MAIN SHAFT 1
8 - SLEW PINION 1
9 - BUSH 1
10 - LOCKING CAP 1
11 - STUD 1
12 - SELF-LOCKING NUT 1
13 - KEY 1
14 - KEY 1
15 - BEARING 1
16 - CIRCLIP 1
17 - SEAL 1
18 - BEARING 1
19 - CIRCLIP 1
20 - SEAL 1
21 - SEALOCK PIN 1
22 - CIRCLIP 1
23 - BEARING 1
24 - CIRCLIP 1
25 - BEARING 1
26 - SEAL 1
27
- CIRCLIP 1
