Upright TL33 - Cage Assembly

7-6b
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
CAGE ASSEMBLY Serial Numbers 1430 to current
ITEM PART-NUMBER DESCRIPTION QTY.
1
*
57521-300
57524-300
CAGE RAIL ASSEMBLY
DROP BAR ASSEMBLY
1
1
2 57344-300 CAGE FLOOR WELDMENT 1
3 57523-300 UPPER CONTROL BOX MOUNTING PLATE 1
4
4
57181-000
57181-001
UPPER CONTROL BOX - SERIAL NUMBERS 1001 TO 1132
UPPER CONTROL BOX - SERIAL NUMBERS 1132 TO CURRENT
1
1
5 57190-400 TAILBOARD ASSEMBLY 1
6
*
*
10076-000
57009-000
57008-000
SERVICE MANUAL / OPERATOR INSTRUCTIONS HOLDER
SERVICE MANUAL (THIS MANUAL)
OPERATORS INSTRUCTIONS
1
1
1
7
*
58244-300
58245-300
TAILBOARD PROTECTOR
TAILBOARD PROTECTOR SECURING LATCH
1
2
8 57348-300 LADDER 1
9 57046-000 BUSHING 2
10 57034-000 CIRCLIP 1
11 57032-300 CIRCLIP 1
12 57027-400 LEVEL ROD PIVOT PIN 1
13 57031-400 BOOM PIVOT PIN 1
14 58251-000 LADDER LOCKING LATCH 1
15 57047-000 BUSHING 1
