Upright TL33 - Brake Assembly

7-12
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
BRAKE ASSEMBLY
57056-000 (L.H.) / 57057-000 (R.H.)
ITEM PART-NUMBER DESCRIPTION QTY.
1 - BACK PLATE L.H. 1
2 - BLANKING PLUG 2
3 - ADJUSTING WEDGE NUT 1
4 - SIDE WEDGE 2
5 - BOLT 1
6 - RETAINING CAP 1
7 - EXPANDER ASSEMBLY 1
8 - SHOE CARRIER 1
9 57138-000 REVERSING SHOE 1
10 57139-000 STANDARD SHOE 1
11 - RETAINING SPRING 1
12 - REVERSING SHOE SPRING 2
13 - TOP SPRING 1
14 - BOTTOM SPRING 1
15 - CABLE BRACKET TOP HALF 1
16 - EYELET 1
17 - BACKPLATE RIGHT HAND 1
