Upright TL33 - Upper Control Box Assembly

7-32
TL33 Work Platform
Illustrated Parts Breakdown
Section
7.2
UPPER CONTROL BOX ASSEMBLY
57181-000 SERIAL NUMBERS 1001 TO 1132
57181-001 SERIAL NUMBERS 1133 TO CURRENT
ITEM PART-NUMBER DESCRIPTION QTY.
1 57324-400 ENCLOSURE 1
2
*
*
*
57325-400
63975-004
58984-000
58985-000
JOYSTICK
POT ASSY
RUBBER BOOT
INTERNAL MICRO SWITCH
1
1
1
1
3
*
*
58152-000
58947-000
58946-000
3-POSITION SELECTOR SWITCH
CONTACT BLOCK N/C
CONTACT BLOCK N/O
1
2
2
4 57309-000 EMERGENCY STOP BUTTON 1
5
*
*
57327-400
58947-000
58946-000
ROTARY SWITCH
CONTACT BLOCK N/C
CONTACT BLOCK N/O
1
1
3
6 57328-400 ALARM 1
7 57329-000 GREEN LED (OUTRIGGERS PROPERLY DEPLOYED) 1
8 57330-000 RED LED (BATTERY WARNING) 1
9 57236-000 P.C.B., UPPER 1
