Upright TL33 - Coupling Assembly

7-20
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
COUPLING ASSEMBLY
(a) 57081-300 SERIAL NUMBERS 1001 TO 1410
ITEM PART-NUMBER DESCRIPTION QTY.
1(a) 57481-000 LEVER ASSEMBLY 1
2(a) 57486-000 BREAKAWAY SAFETY CABLE 1
4(a) 58789-000 GAITER 1
5(a) 57491-000
57490-000
COUPLING HEAD (EUROPE)
COUPLING HEAD (USA)
1
1
** 57461-000 CLAMP SLEEVE ASSEMBLY FOR JOCKEYWHEEL 1
ITEM ** NOT SHOWN - USED TO CLAMP JOCKEY WHEEL TO COUPLING.
(b) 58240-300 SERIAL NUMBERS 1411 TO CURRENT (EXCLUDING GERMAN MACHINES (TYPE (a) USED))
ITEM PART-NUMBER DESCRIPTION QTY.
1(b) 58787-000 LEVER ASSEMBLY 1
2(b) 57486-000 BREAKAWAY SAFETY CABLE 1
3(b) 58794-000 SPRING PACK ASSEMBLY 1
4(b) 58790-000 GAITER 1
5(b) 58791-000
58792-000
COUPLING HEAD (EUROPE)
COUPLING HEAD (USA)
1
1
** 58263-000 CLAMP PLATE ASSEMBLY FOR JOCKEY WHEEL 1
