Upright TL33 - Main Manifold Block

7-24
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
MAIN MANIFOLD BLOCK
ITEM PART-NUMBER DESCRIPTION QTY.
1 57106-000 PRESSURE TEST POINT FITTING 1
2 57373-000 RELIEF VALVE 1
3 57371-000 SOLENOID VALVE CARTRIDGE INCLUDING COIL (SLEW) 2
4 57372-000 SOLENOID VALVE CARTRIDGE INCLUDING COIL (CYLINDERS) 2
5 57370-000 MANIFOLD BODY 1
6 57121-000 M/M ADAPTOR 3/8” - 1/4” B.S.P. 6
7 57125-000 BONDED SEAL - 3/8” 9
8 57123-000 M/M ADAPTOR 3/8” - 1/2” B.S.P 1
9 57122-000 M/M ADAPTOR 3/8” - 3/8” B.S.P 1
10 58255-000 LOCKNUT 4
