Upright TL33 - Lift Cylinder Assembly

7-26
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
UPPER & LOWER LIFT CYLINDER ASSEMBLY
57104-300
ITEM PART-NUMBER DESCRIPTION QTY.
1 - CYLINDER BODY 1
2 57368-000 VALVE BLOCK 1
3 57378-000 SINGLE OVERCENTRE CARTRIDGE - 175 BAR 1
4 - END CAP 1
5 - ROD AND END PIVOT 1
6 SEE NOTE ROD SEAL 2
7 SEE NOTE O-RING 1
8 SEE NOTE WIPER 1
9 SEE NOTE PISTON O-RING 1
10 58819-000 GREASE NIPPLE 2
11 - PISTON HEAD 1
12 SEE NOTE PISTON SEAL 1
13 SEE NOTE PISTON LOCKNUT 1
14 57472-000 EMERGENCY LOWERING CARTRIDGE VALVE 1
15 - O-RING 1
NOTE: ITEMS 6,7,8,9,12 & 13ALL FORM THE SEAL KIT FOR THE CYLINDER.
THE SEAL KIT IS 57360-300
