Upright TL33 - Tailboard Assembly

7-18 TL33 Work Platform
Illustrated Parts Breakdown
Section
7.2
TAILBOARD ASSEMBLY
57190-000 (SERIAL NUMBERS 1001 TO 1410)
ITEM PART-NUMBER DESCRIPTION QTY.
1 58736-000 BRAKE/INDICATOR ASSEMBLY COMPLETE 2
2 58739-000 REFLECTOR 2
3 58738-000 FOG LIGHT ASSEMBLY COMPLETE 2
4 57280-000 BRAKE/INDICATOR LENS 2
5 57237-000 FOG LIGHT LENS 2
6
*
57334-000
57335-000
7-PIN PLUG
7- PIN SOCKET
2
2
57190-001 (SERIAL NUMBERS 1411 TO CURRENT)
ITEM PART-NUMBER DESCRIPTION QTY.
1 58260-000 BRAKE/INDICATOR ASSEMBLY COMPLETE 2
2 58739-000 REFLECTOR 2
3 58738-000 FOG LIGHT ASSEMBLY COMPLETE 2
4 58261-000 BRAKE/INDICATOR LENS 2
5 57237-000 FOG LIGHT LENS 2
6
*
57334-000
57335-000
7-PIN PLUG
7- PIN SOCKET
2
2
7 58262-000 NUMBER PLATE LIGHT ASSEMBLY COMPLETE 2
