Upright TL33 - CAGE ASSEMBLY

7-6a TL33 Work Platform
Schematics
Sectio
n
7.2
CAGE ASSEMBLY Serial Numbers 1001 to 1429
ITEM PART-NUMBER DESCRIPTION QTY.
1 57091-300 CAGE RAIL ASSEMBLY 1
2 57090-300 CAGE FLOOR WELDMENT 1
3 58038-300 UPPER CONTROL BOX MOUNTING PLATE 1
4
4
57181-000
57181-001
UPPER CONTROL BOX - SERIAL NUMBERS 1001 TO 1132
UPPER CONTROL BOX - SERIAL NUMBERS 1132 TO CURRENT
1
1
5 57212-300 MOUNTING PANEL 1
6
*
03613-000
57008-000
OPERATOR INSTRUCTIONS HOLDER
OPERATORS INSTRUCTIONS
1
1
7 57190-400 TAILBOARD ASSEMBLY 1
8 57092-300 LADDER 1
9 57046-000 BUSHING 2
10 57034-000 CIRCLIP 1
11 57032-300 CIRCLIP 1
12 57027-400 LEVEL ROD PIVOT PIN 1
13 57031-400 BOOM PIVOT PIN 1
14 57047-000 BUSHING 1
