Upright TL33 - BOOMS AND POSTS ASSEMBLY

7-4 TL33 Work Platform
Illustrated Parts Breakdown
Section
7.2
BOOMS AND POSTS ASSEMBLY
ITEM PART-NUMBER DESCRIPTION QTY.
1 57035-200 FIRST POST WELDMENT 1
2 57039--300 TENSION BAR WELDMENT 2
3 57037-300 LOWER BOOM WELDMENT 1
4 57036-300 SECOND POST WELDMENT 1
5 57038-300 UPPER BOOM WELDMENT 1
6 57040-300 LEVELLING ROD WELDMENT 1
7
57104-300 1ST POST CYLINDER ASSY
1
8
57104-300 2ND POST CYLINDER ASSY
1
9 57453-300 1ST POST COVER 1
10 57043-300 SLEWRING BEARING 1
11
57041-300 SLEW GEARBOX AND PINION
1
12 57180-300 LOWER CONTROL BOX ASSEMBLY 1
13
57105-300 MANIFOLD BLOCK ASSEMBLY
1
14
*
57350-300
57473-000
SLEW MOTOR
SEAL KIT
1
1
15 57027-400 TENSION BAR PIVOT PIN 5
16 57031-400 BOOM PIVOT PIN 3
17 57028-400 CYLINDER BODY PIVOT PIN 2
18 57029-400 CYLINDER ROD PIVOT PIN 2
19 57054-000 30MM I.D. FLANGED BUSH 8
20 57033-000 CIRCLIP 4
21 57047-000 25MM I.D. BUSHING 5
22 57032-000 CIRCLIP 5
23 57046-000 35MM I.D. BUSHING 6
24 57034-000 CIRCLIP 3
25 57049-300 BOOM REST BUFFER 1
