Upright TL33 - Page 77

7-16
TL33 Work Platform
Illustrated Parts Breakdown
Sectio
n
7.2
LOWER CONTROL BOX AND HARNESSES
ITEM PART-NUMBER DESCRIPTION QTY.
1 57306-000 ENCLOSURE 1
2 57307-400
57476-000
58252-300
P.C.B. ASSEMBLY SERIAL NUMBERS 1001 TO 1132
P.C.B. ASSEMBLY SERIAL NUMBERS 1133 TO 1330
P.C.B. ASSEMBLY SERIAL NUMBERS 1331 TO CURRENT
1
1
1
3 57308-000 CABLE GLAND (SMALL) 11
4 57332-000 CABLE GLAND (LARGE) 2
5 57309-400 EMERGENCY STOP COMPLETE 1
6 57310-400 KEYSWITCH COMPLETE 1
7 57311-400 TOGGLE SWITCH 3
8 57313-400 HARNESS - INTERNAL 1
9 57317-400 HARNESS -TO SLEW CUT-OUT LIMIT SWITCH 1
10 57318-400 HARNESS - TO FRONT LEFT OUTRIGGER LIMIT SWITCH 1
11 57319-400 HARNESS - TO FRONT RIGHT OUTRIGGER LIMIT SWITCH 1
12 57320-400 HARNESS - TO REAR RIGHT OUTRIGGER LIMIT SWITCH 1
13 57321-400 HARNESS - TO REAR LEFT OUTRIGGER LIMIT SWITCH 1
14 57322-400 HARNESS - LOWER CONTROL BOX TO UPPER CONTROL BOX 1
15 57323-400 HARNESS - TO MOTOR CONTROL UNIT 1
16 57451-300 MOUNTING PLATE 1
17 57322-400 HARNESS - TO TILT ALARM 1
18 57292-400 HARNESS - TO SOLENOIDS 1
