Upright TL33 - Page 92

7-30
TL33 Work Platform
Illustrated Parts Breakdown
Section
7.2
PUMP MOTOR CONTROL UNIT ASSEMBLY
57192-000 = COMPLETE ASSLEMBY (NO LINE CONTACTOR) SERIAL NUMBERS 1001 TO 1132
57192-001 = COMPLETE ASSEMBLY - SERIAL NUMBERS 1133 TO CURRENT
ITEM PART
NUMBER
DESCRIPTION QTY.
1
*
57300-400
57475-300
CONTROLLER UNIT SERIAL NUMBERS 1001 TO 1132
CONTROLLER UNIT SERIAL NUMBERS 1133 TO CURRENT
1
2 57304-000 FUSE 160A 1
3 57485-000
LINE CONTACTOR - SERIAL NUMBERS 1133 TO CURRENT ONLY
1
4 57470-000 FUSE 7A 1
5 58932-000 SUPRESSION DIODE ASSY. 1
6
* NOT
SHOWN
57128-000 MOS 90 CALIBRATOR - TEST/PROGRAMMING INSTRUMENT 1
