Operation
36
11. The locking device 2 can be used to fix the trigger in an opened position.
Pulling on the trigger again releases the locking device.
The dosing will not be triggered if the battery voltage is too low (protection
against exhaustive discharge, see figure 6/4). Charge the battery first.
When the locking device is fixed (see figure 6/3 on page 36), you can press
the key to dose the required feed amount several times without having
to actuate the trigger again.
6.3.1.3 Charge condition
The charge condition of the battery or batteries is displayed in the "Feeding"
function. The voltages are shown as bar graph on the right. The five squares in
Row 1 (optional) indicate the charge condition for the propelling drive.
You can assess the battery charge condition here:
➊ Actuate the trigger
➋ Fix with locking device
Figure 6/3: Actuate the pump nozzle
Information
When not in use, connect the device to the power supply. This keeps the
batteries charged and ready for operation.
To check the charge condition, you must unplug the power plug in order
for the correct value to be displayed.
Charge battery now! Battery ready for operation Battery fully charged
Figure 6/4: Display of battery charge condition
Feeding █████
1: 04,0 █████
