Jumpers on the Internal Courier
Locating Jumpers
Your internal Courier V.Everything is set to Plug and Play. You shouldn’t
have to change this setting, however, if you have multiple devices
connected to your system, you may need to change the jumper settings to
avoid hardware conflicts.
Figure 8.5 Jumpers on the Internal Courier
Changing Jumper Settings
You can add shunts (see figure 8.7) to cover sets of pins on the jumper
blocks (see figure 8.6).
Caution: If you do not have any hardware conflicts, you do not need to
use this section.
