7-6 Courier V.Everything Getting Started Guide
Setting Jumpers for a Specific IRQ
You can put shunts on the IRQ jumper block to configure the desired IRQ:
To set your modem to To set the jumpers to
IRQ 3
IRQ 4
IRQ 5
IRQ 7
IRQ 9
