2. DESCRIPTION OF GROUPS
2.1 Monitor group: menu MON
VACON
®
20 CP/X AC drive provides you with a possibility to monitor the actual values of pa-
rameters and signals as well as statuses and measurements. Some of the values to be moni-
tored are adjusted. See Table 25, Table 26, Table 27 and Table 28 in which the monitoring
values are presented.
2.1.1 ASi
Table 25: ASi monitoring items.
NOTE: these values are valid only with Vacon 20 CP/X +D and AS-interface connection.
2.1.2 Sensors
Table 26: Sensors monitoring item.
2.1.3 Motor
Table 27: Motor monitoring items.
Code Monitoring value Unit ID Level Description
V1.1 ASi Outputs 4, 3, 2,1 1879 Basic State of received bits on ASi board
V1.2 ASi Inputs 4, 3, 2, 1 1878 Basic State of transmitted bits on ASi board
V1.3 ASi board state Basic
0: power off
1: communication ok
2: no master
3: address=0
4: periphery fault
5: serious periphery fault
Code Monitoring value Unit ID Level Description
V2.1 Sensors 4, 3, 2, 1 1885 Basic State of sensors read on digital inputs
Code Monitoring value Unit ID Level Description
V3.1 Output frequency Hz 1 Basic Output frequency to motor
V3.2 Frequency reference Hz 11 Basic Frequency reference to motor control
V3.3 Motor speed rpm 2 Basic Motor speed in rpm
V3.4 Motor current A 3 Basic
V3.5 Motor torque % 4 Advanced Calculated shaft torque
V3.6 Motor shaft power % 5 Advanced Total power consumption of AC drive
V3.7 Motor voltage V 6 Advanced
V3.8 Motor temperature % 9 Advanced Calculated motor temperature
V3.9 Process variable 29 Advanced Scaled process variable
