3.13 Analogue Output
P13.1 ANALOGUE OUTPUT FUNCTION
Signal coupled to analogue output.
P13.2 A
NALOGUE OUTPUT MINIMUM SIGNAL
0: 0V
1: 2V
P13.3 A
NALOGUE OUTPUT SCALING
Scaling factor.
P13.4 A
NALOGUE OUTPUT FILTER TIME
Time constant of low pass filter.
Note: analogue output terminals are not accessible in standard Vacon 20X+D drive.
3.14 User interface
P14.1 PARAMETERS ACCESS LEVEL
See chapter 1
0: Basic
1: Advanced
2: Service
P14.2 P
ARAMETERS LOCK
0: Edit enabled
1: Edit disabled
Selection Selection name Value corresponding to maximum output
0 Not used output always fixed at 100%
1 Frequency reference Max frequency(P3.2)
2 Output frequency Max frequency(P3.2)
3 Motor speed Motor nominal speed
4 Motor current Motor nominal current
5 Motor torque Motor nominal torque (absolute value)
6 Motor power Motor nominal power (absolute value)
Table 48. Analogue output signals.

Vacon 20 SERIES Specifications

General

Output Voltage	0 to Input Voltage
Storage Temperature	-40°C to +70°C
Dimensions	Varies by model
Weight	Varies by model
Power Range	0.25 kW to 18.5 kW
Voltage Range	200 V to 480 V
Control Method	Sensorless vector control
Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Communication Options	Modbus, CANopen
EMC Filter	Integrated
STO (Safe Torque Off)	Yes
Input Voltage	208-240 V, 380-480 V
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% non-condensing
