Vacon 20 SERIES User Manual

Description of Groups vacon • 16
Service support: find your nearest Vacon service center at www.vacon.com
2
2.2.2 Group Start/Stop Settings: Menu PAR G2
Code Parameter Min Max Unit Default ID Level Description
P2.1
AUTO
Start/Stop logic
0 3 0 300 Basic
Logic = 0:
Start sgn 1 = Start Forward
Start sgn 2 = Start Back-
ward
Logic =1:
Start sgn 1 = Start Forward
(edge)
Start sgn 2 = Start Back-
ward (edge)
Logic = 2:
Start sgn 1 = Start
Start sgn 2 = Reverse
Logic = 3:
Start sgn 1 = Start (edge)
Start sgn 2 = Reverse
P2.2
AUTO
Run control
0 1* 1 125 Advanced
0= Start 1-Start 2 signals
1= non-ASi fieldbus
P2.3 Start function 0 1 0 505 Advanced
0=Ramping
1=Flying start
P2.4 Stop function 0 1 0 506 Advanced
0=Coasting
1=Ramping
P2.5 Quick Stop Function 0 1 0 1896 Basic
0=Signal level
1=Signal edge
P2.6 Manual Start mode 0 1 1 1899 Advanced
0=Signal level
1=Signal edge
Table 31: Group Start/Stop settings.
NOTE!
(*)Selection 1 is available only if ASi board is not installed. In this case a different
fieldbus can be used to control the drive. When ASi board is installed this param-
eter is automatically set to 0.

Vacon 20 SERIES Specifications

General

Output Voltage	0 to Input Voltage
Storage Temperature	-40°C to +70°C
Dimensions	Varies by model
Weight	Varies by model
Power Range	0.25 kW to 18.5 kW
Voltage Range	200 V to 480 V
Control Method	Sensorless vector control
Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Communication Options	Modbus, CANopen
EMC Filter	Integrated
STO (Safe Torque Off)	Yes
Input Voltage	208-240 V, 380-480 V
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% non-condensing
