3.5 Input functions
P5.1 START SIGNAL 1
P5.2 S
TART SIGNAL 2
Signals for start and direction. Logic is selected with P2.1.
0: Function not used
1: ASi Output 1
2: ASi Output 2
3: ASi Output 3
4: ASi Output 4
5: Sensor 1
6: Sensor 2
7: Sensor 3
8: Sensor 4
P5.3 P
RESET SPEED BIT0
P5.4 P
RESET SPEED BIT1
P5.5 P
RESET SPEED BIT2
Signals for preset speed selection, with binary coding.
P5.6 F
AULT RESET
Active on rising edge.
Note: an automatic fault reset is triggered when Manual mode is activated on operator panel.
P5.7 F
ORCE BRAKE
Signal high opens the mechanical brake.
Required action Activated frequency
B2 B1 B0 Preset frequency 0
B2 B1 B0 Preset frequency 1
B2 B1 B0 Preset frequency 2
B2 B1 B0 Preset frequency 3
B2 B1 B0 Preset frequency 4
B2 B1 B0 Preset frequency 5
B2 B1 B0 Preset frequency 6
B2 B1 B0 Preset frequency 7
Table 45. Selection of preset frequencies; = input activated
