Vacon 20 SERIES User Manual

vacon • 31 Description of Groups
2
P2.5 Input assembly type 70 117 71 14013
When OPTE3/E5(Profibus) option board has been installed, the following values are visible:
V2.1
Profibus communication sta-
tus
14022
P2.2 Fieldbus protocol 14023
P2.3 Active protocol 14024
P2.4 Active baud rate 14025
P2.5 Telegram type 14027
P2.6 Operate mode 1 3 1 14021
P2.7 Slave address 2 126 126 14020
Other information:
V3.1 MWh counter 827
V3.2 Power on day counter 828
V3.3 Power on hour counter 829
V3.4 RUN day counter 840
V3.5 RUN hour counter 841
V3.6 Fault counter 842
V3.7
Panel parameter set status
monitor
Hidden when PC is connected
P4.2 Restore factory defaults 0 1 0 831
1 = Restore factory defaults
for all parameters
P4.3 Password 0 9999
000
0
832
P4.4 Time for keypad backlight 0 99 min 5 833
P4.5 Save parameters to Keypad 0 1 0
1= Upload all parameters to
Keypad
Hidden when PC is connected.
This function works properly
only with drive supplied.
P4.6
Download parameters from
Keypad
01 0
1= Download all parameters
to Keypad
Hidden when PC is connected.
This function works properly
only with drive supplied.
F5.x Active fault menu 0 9
F6.x Fault history menu 0 9
Table 44: System parameters, Faults and History faults.

Vacon 20 SERIES Specifications

General

Output Voltage	0 to Input Voltage
Storage Temperature	-40°C to +70°C
Dimensions	Varies by model
Weight	Varies by model
Power Range	0.25 kW to 18.5 kW
Voltage Range	200 V to 480 V
Control Method	Sensorless vector control
Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Communication Options	Modbus, CANopen
EMC Filter	Integrated
STO (Safe Torque Off)	Yes
Input Voltage	208-240 V, 380-480 V
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% non-condensing
