USER'S GUIDE____________________________________________________________________
128 _________________________________________________________________ M210482EN-D
External Connector J2 - Power Input
Table 27 Power Input
Property Description / Value
At nominal line voltage 100V or 115 V or 230 V
Power consumption (typical):
Total
Measurement unit
Internal heater
Window conditioner heater
Window blower
310 W
15 W
100 W
175 W
20 W
Frequency 45-65 Hz
Power connector (J2) Type Binder series 693, 09-4223-00-04
4-pin (male)
Mating connector type Type Binder series 693, 99-4222-70-04
(female) elbow
No-break power supply 12 V Sealed Lead Acid Battery, 2 Ah
Overvoltage protection Low-pass filter , VDR
Output Interface
The data port can operate according to the following serial line standards:
RS-232
RS-485, multidrop, 2-wire
The data port can also be operated through a DMX501 modem module.
The maintenance port is an RS-232 serial line.
External Connector J3 - Data Line
The data line is intended to be used for measurement data
communication, but it can also be used with a Ceilometer Maintenance
Terminal, PC, or other terminals.
