MC095 - MCP-8 Control Unit Section 4 - Programming
35
Section 4 - Programming
Programming
The Operator Interface Buttons
Refer to Figure 3-1.
The Status LEDs
Status LEDs - The Status Display LEDs show on/off status. When an LED is on (lit up), the corresponding input or
output is activated (see Figure 4-2).
Be sure the encoder, scanners, valves, and the MCP-8 Control Unit
have been properly mounted to the parent machine before setting up
the control. The glue and air lines are not connected until after the
control is programmed.
Figure 4-2. Status LEDs
