MC095 - MCP-8 Control Unit Section 7 - Specifications
77
Section 7 - Specifications
Item MCP-8 Unit
Control dimensions:
Height: 9.95 (252.6 mm)
Depth: 7.81 (198.3 mm)
13.95 (354.2 mm)
Input voltage: 100-240 VAC, 50-60 Hz (auto-selectable)
Number of channels: 8-channel operation with up to 8 programmable patterns per channel
Glue pattern resolution: 0.01 in. or 1 mm
Minimum Glue Pattern Length* Approximately 2 mm for an MX valve; 5mm for cold glue valves
Maximum Glue Pattern Length 6554 mm
Number of scanner inputs: Up to 8 with scanner lockout
Glue pattern tolerance: Less than 1 mm (.04 inches) at 610 m/min (2000 ft/min)
Job storage memory: Up to 1000 jobs
Miscellaneous:
Dual-encoder-based or timer mode
Multi-valve, complex glue pattern capabilities
“Continuous,” “Stitch” pattern and “Jogg” gluing
Adjustable minimum speed
Inch or metric calibration
CE compliant
Password protection for key system parameters
Integral fluid-flow control option (EPC) and external EPC output
Web break detection option
Batch count/production count
Programmable valve output voltages depending upon base unit
Jam Preventer w/Alarm and relay output
* The minimum glue pattern lengths depend upon the valve type, due to the varying amount of time it takes to open the valve.
