3.7.1 Adjusting trailer hitch height - Models with holes guide rail
Procedure
1. Support the hitch (A).
2. Remove the locking pins (B) and pins (C).
3. Bring the hitch (A) to the required position.
4. Re-install the pins (C) and the locking pins (B)
once the desired setting is obtained.
IMPORTANT:
Use only trailers with a towing eye that
matches the hitch pin diameter.
NOTE:
Check and replace if needed wear or
damaged parts.
GUID-4FCF76A9-F4F1-4B8F-8A94-D7ED84FC23FE-low.png [Low]
Fig. 131
GUID-AC4FFE94-0F94-4432-8421-AE3A27B82720 [V1]
