When you select the fast range with the (+)
button, the indicator lamp (B) comes on. When you
select the slow range with the (-) button, the
indicator lamp (B) goes o.
GUID-17A6BF0E-B055-43EE-899B-740B2A71695D-low.png [Low]
Fig. 12
3.1.3 Clutch, brakes and throttle
3.1.3.1 Clutch
Clutch pedal
Use the clutch pedal to attach an implement in a
controlled mode or during a very hard movement.
It disengages the clutch when fully pressed.
GUID-42B63D94-DB7B-4E27-886A-89DE2C977D0D-low.png [Low]
Fig. 13 With cab
GUID-30D88BB3-244B-482D-B24F-B2B8AFA9527F-low.png [Low]
Fig. 14 With ROPS
[V]
GUID-DE0377FF-3FC1-4434-98CC-7190CB64290E [V1]
3. Operation
F Series 61
39940211 (555124)
