4.12.4 Transmission/Hydraulic System Oil Level Check
Remove the dipstick (A), wipe clean and re-insert it
fully. Remove again the dipstick and check the oil
level. The oil level should be between the full mark
and the end of the dipstick.
IMPORTANT:
If using implements that require a greater quantity
of oil in the hydraulic circuit, the oil level must be
up to the mark “XXX”.
GUID-5F092097-124C-4FF6-AAC8-28E766F366E5-low.png [Low]
Fig. 71
4.12.5 Brake fluid level check
GUID-9CA02F84-5157-429F-95D2-1A59B2F7340B-high.jpg [High]
Fig. 72
Examine the brake fluid level through the inspection scale on the brake fluid reservoir.
GUID-74BCA387-DD69-4BCF-B3D5-9B50573577EB [V2]
GUID-1C3EDD16-3E45-4A81-887E-8BAC373D89EA [V1]
4. Maintenance
182 F Series
39940211 (555124)
