16. Put a container below the fuel tank and
remove the drain plug (G).
17. Drain the fuel tank fully.
18. Install and tighten the drain plug (G).
19. Fill the tank with new fuel.
GUID-EEAD44AB-1D03-4BD1-A6AA-5FC7A4F4C7DA-high.jpg [High]
Fig. 115
4.12.20 Engine Oil and Filter Replacement
Liquid drain
1. Drain the oil when the engine is warm,
remove the plugs (1) (one for side) from the
engine sump with the tractor standing on
level ground.
2. Refit and tighten the drain plug to a torque of
35 Nm.
GUID-450BF343-2ACB-4083-B407-1F791B01FFF0-low.png [Low]
Fig. 116
To change the filter (A) proceed as follows:
3. Unscrew and discard the filter assembly.
4. Fill the new filter slowly with clean oil.
5. Smear a few drops of clean engine oil on the
new sealing ring, then place it on top of the
new filter.
6. Screw the filter onto the filter head until the
sealing ring just contacts the filter head, then
tighten it further half turn by hand only (do
not over tighten).
7. Ensure that there is lubricating oil in the
sump.
GUID-9D4A80C7-4982-4B1B-8BBE-46B4F0B6B0D7-low.png [Low]
Fig. 117
GUID-BD7BED81-EC60-48EC-8A92-7E3981C0F71B [V1]
4. Maintenance
F Series 203
39940211 (555124)
