Valtra F Series

5.7.2 Rear track
GUID-CE5783A2-D972-4E14-8BCA-10914CBF76C9-low.png [Low]
Fig. 10
8 position adjustable rims
Standard Dimension (mm)
A B C D E F G H
380/70
R24
- - 1196 1039 1195 1308 1364 1477
420/70
R24
- - 1196 1309 1195 1308 1364 1477
380/70
R28
- - 1114 1225 1277 1388 1514 -
420/70
R28
- - 1114 1225 1277 1388 1514 -
480/65
R28
- - - 1217 1285 1396 - -
GUID-FDC5A8D6-24D1-474C-A212-45528D7221FD [V1]
5. Specifications
F Series 227
39940211 (555124)
