3. Move the seat forward for access.
GUID-C7A397DA-A350-462F-A30C-34BEC24E4B53-high.jpg [High]
Fig. 5
4. Remove the fasteners.
GUID-1C1D277B-C4A5-4444-88C2-386ECB5C903A-high.jpg [High]
Fig. 6
5. Remove the cover.
6. Release the protective covers from the positive and negative connectors.
7. Disconnect the positive (1) and negative (2)
connectors from the battery.
GUID-8068D53D-D64D-4202-A2E8-B25B1A71342B-high.jpg [High]
Fig. 7
8. Loosen the fasteners (3).
9. Remove the battery.
4. Maintenance
146 F Series
39940211 (555124)
