3. Push the fastener down and turn it
counterclockwise. Remove the fastener (B).
GUID-B5D7D7DD-8188-4019-BC00-35B35D79DB99-high.jpg [High]
Fig. 45
4. IMPORTANT:
Do not touch the glass section of the bulb.
This can decrease the life of the bulb.
Remove the bulb (C).
5. Install the new bulb.
GUID-209EC6EF-4210-4FCC-80A1-6B476B900839-high.jpg [High]
Fig. 46
6. Push the spring down with the fastener and
turn the fastener clockwise.
GUID-B5D7D7DD-8188-4019-BC00-35B35D79DB99-high.jpg [High]
Fig. 47
7. Turn the cover (A) clockwise to install the
lens.
GUID-FA4AA98F-CE66-4ACD-9568-4CD453279575-high.jpg [High]
Fig. 48
4. Maintenance
166 F Series
39940211 (555124)
