Valtra F Series

Dimension Definition Narrow Standard
A1 Maximum length for road
use
4940 mm 4940 mm
B Minimum width for road
use
1278 mm 1227 mm
B Maximum width for road
use
1785 mm 1951 mm
C Maximum height for road
use
1803 mm 1803 mm
D Wheelbase 2148 mm 2124 mm
E Rear track minimum
width
955 mm 947 mm
E Rear track maximum
width
1359 mm 1555 mm
E1 Front track minimum
width
850 mm 1129 mm
E1 Front track maximum
width
1148 mm 1603 mm
F Rear overhang 1083 mm 1083 mm
G Ground clearance with
front ballast weight
195 mm 270 mm
G Ground clearance
without front ballast
weight
295 mm 316 mm
H Front overhang 1709 mm 1733 mm
I Maximum rear slope-out
angle
12° 12°
L Maximum front slope-in
angle
9° 9°
M Front overhang without
front lift
970 mm 994 mm
5. Specifications
F Series 231
39940211 (555124)
